Support & FAQ

Everything you need to know about VoltSense

Frequently Asked Questions

🔋 VoltSense P2 Device

What is the VoltSense P2?
VoltSense P2 is a smart marine monitoring device that continuously tracks your boat's battery voltages, temperature, humidity, movement, and location. It ensures your boat remains in optimal condition year-round — both in the water and during storage.
How does VoltSense P2 connect to my boat?
The device includes a pre-wired 1.5 m cable harness. Simply connect:
  • BAT1 to the house battery's positive terminal
  • BAT2 to Engine 1 battery
  • BAT3 to Engine 2 battery (if applicable)
It can also connect to optional accessories like a bilge pump sensor or EYE Sensor (BTSMP1).
Does VoltSense P2 need a SIM card or Wi-Fi?
No setup is needed — P2 includes a built-in cellular module with global connectivity using LTE-M/NB-IoT. Data is securely sent to the VoltSense HUB automatically.
How long does the internal battery last?
Up to 3 months in autonomous mode without external power, depending on data transmission frequency and temperature.
Can I see live data from my boat?
Yes. You can access real-time and historical data anytime through the VoltSense Mobile App or HUB Portal.
What parameters does P2 monitor?
  • Battery voltages (up to 3 circuits)
  • Temperature and humidity
  • Movement and impact (G-sensor)
  • GPS location
  • Optional accessories (e.g., EYE Sensor, bilge pump)
How accurate are the measurements?
Voltage readings are accurate within ±0.05 V; temperature within ±1 °C; humidity within ±3 %. GPS accuracy typically ±5 m outdoors.
Can I install VoltSense P2 myself?
Yes. It's designed for DIY installation — only connect the wires to the battery positives and mount the device securely inside the boat. Use marine-grade screws or brackets.
Where should I mount the device?
Choose a dry, stable area with a clear view to the sky through fiberglass or plastic surfaces to ensure good GPS reception. Avoid placing it under metal covers.
Is VoltSense waterproof?
The P2 is IP65-rated — splash-proof and resistant to marine humidity. It should not be submerged.
Can multiple users access one boat's data?
Yes, the boat owner can share access rights via the VoltSense HUB, allowing service providers or marinas to view battery and sensor data.

🖥️ E-Paper Screen

What is the VoltSense E-Paper Display?
It's a low-power digital tag that shows your boat's status — battery voltage, temperature and humidity — directly at the dock or storage area.
How does it update the data?
The display connects wirelessly to the VoltSense P2 device and updates automatically whenever new data is transmitted to the HUB.
Does it require charging?
No. The E-Paper screen is powered by a coin-cell battery lasting up to 2 years, depending on update frequency.
Can I customize what the screen shows?
Yes. Through the VoltSense HUB you can choose which parameters appear (e.g., main battery voltage, last update time, temperature, etc.).
Is the display waterproof?
It's designed for outdoor use and resistant to humidity and splashes (IP54). Avoid full submersion or prolonged direct rain exposure.
Where can I place it?
Typically near the boat slip, on a dashboard, or near the storage location — anywhere with short wireless range to the P2 device.

👁️ EYE Sensor (BTSMP1)

What is the EYE Sensor?
The EYE Sensor (Teltonika BTSMP1) is a compact Bluetooth Low Energy (BLE) beacon with four built-in sensors: temperature, humidity, movement (accelerometer), and magnet detection. It's pre-configured to work seamlessly with VoltSense P2 for extended environmental and asset monitoring.
How do I connect EYE Sensor to VoltSense P2?
Simply power up the sensor and open the VoltSense App → Device Settings → Add Sensor. The P2 will automatically detect nearby EYE Sensors via Bluetooth and link them. Each sensor comes pre-configured for easy pairing.
How many EYE Sensors can I use?
You can connect up to 5 EYE Sensors to one VoltSense P2 device — for example, one in the cabin, one in the engine room, one near the batteries, one on the door/hatch, and one in the refrigerator.
What is the range between P2 and EYE Sensor?
Up to 80 meters in open space. In typical boat environments with walls and equipment, expect 10-30 meters effective range depending on materials.
Do EYE Sensors require power?
They operate on a CR2450 lithium coin-cell battery (600 mAh, pre-installed). Battery life is 4+ years with default settings (5s interval) or up to 5+ years with 10s interval. The battery is non-replaceable.
What data is shown in the app?
Each connected EYE Sensor displays temperature (-20°C to +60°C), humidity (0-100%), movement/accelerometer events (pitch, roll, impact detection), and magnet detection status (useful for door/hatch open/close alerts).
What are common use cases for EYE Sensors?
  • Cold chain monitoring: Track refrigerator/freezer temperatures
  • Door/hatch alerts: Use magnet sensor to detect when doors, hatches, or compartments are opened
  • Movement detection: Security alerts for unauthorized movement or theft
  • Environmental monitoring: Multiple cabin zones, engine room humidity
  • Asset tracking: Monitor trailers, containers, or equipment
Is the EYE Sensor waterproof?
Yes, the EYE Sensor has IP67 water resistance rating and can withstand dust, splashes, and temporary submersion. It operates in -20°C to +60°C and handles 0-100% non-condensing humidity.

🌐 VoltSense HUB Portal

What is the VoltSense HUB?
The HUB is a secure web-based platform for managing all your boats, devices, and maintenance activities. It's accessible via any browser at hub.voltsense.eu.
What can I do in the HUB?
  • View real-time data and history from your P2 devices
  • Share boat data with marinas, storage providers, or service companies
  • Manage maintenance logs and service history
  • Set up notifications and alerts
  • Export data for reports or analysis
Can I give temporary access to others?
Yes, you can grant or revoke access at any time — ideal for letting a service provider monitor your boat during storage or maintenance.
How is my data protected?
All communication between devices, apps, and the HUB uses end-to-end encryption (TLS 1.2+) with token-based authentication.
Is there a subscription fee?
Basic monitoring is included with the device. Premium features like maintenance tracking or multi-boat management may require a subscription plan.
Can I monitor multiple boats?
Absolutely. The HUB supports unlimited boats and devices under one account.

📱 VoltSense Mobile App

Where can I download the app?
The VoltSense App is available on the Apple App Store. (Android version coming soon.)
What can I do in the app?
  • Add and register new VoltSense P2 devices
  • View real-time sensor data
  • Receive alerts (low voltage, motion, temperature, etc.)
  • Share access with others
  • Update device firmware when available
How do I connect my device to the app?
Open the app, log in with your VoltSense account, and follow the setup wizard to scan or enter your device's serial number and token.
Can I use the app offline?
Some data (last known values) are cached locally, but live updates require network connection.
What notifications will I receive?
You can choose to get alerts for:
  • Low battery voltage
  • Movement or impact
  • Temperature outside set range
  • Connection loss or inactive device
How often is data updated?
Typical update interval is every 15–30 minutes, depending on your configuration. You can adjust the frequency via the app or HUB.

🧭 General & Support

What's the warranty period?
All VoltSense devices include a 2-year warranty against manufacturing defects.
Where can I buy VoltSense products?
You can order directly from voltsense.eu or from our authorized partners and marine retailers.
How can I contact support?
Email us at support@voltsense.eu or open a ticket in the HUB portal's support section.
Does VoltSense work outside Estonia?
Yes. VoltSense P2 supports international cellular connectivity in most European and Nordic countries, with automatic roaming through our IoT network partners.
Can I integrate VoltSense data with other systems?
The HUB supports API access for professional users and marinas wishing to integrate data into their own dashboards.

Documentation

📖

User Manual

Complete guide for VoltSense P2 installation and usage

Download PDF
🔧

Installation Guide

Step-by-step instructions for DIY installation

Download PDF
📊

Technical Specifications

Detailed technical data and compatibility

View Specs
🔌

API Documentation

Developer guide for HUB API integration

View Docs
🎥

Video Tutorials

Watch installation and setup video guides

Watch Videos
📱

App Guide

How to use the VoltSense mobile app

Download PDF

Warranty Information

2-Year Limited Warranty

All VoltSense products are covered by a comprehensive 2-year warranty from the date of purchase. This warranty covers defects in materials and workmanship under normal use.

What's Covered:

  • Manufacturing defects in hardware components
  • Failure of the device under normal operating conditions
  • Battery performance issues within specifications
  • Connectivity module malfunctions

What's Not Covered:

  • Damage from improper installation or use
  • Physical damage, water damage beyond IP rating, or abuse
  • Unauthorized modifications or repairs
  • Normal wear and tear, including battery degradation over time
  • Damage from accidents, natural disasters, or external forces

How to Make a Warranty Claim:

Contact our support team at support@voltsense.eu with your proof of purchase and a description of the issue. We'll guide you through the warranty process and arrange repair or replacement as needed.

Note: This warranty gives you specific legal rights, and you may also have other rights which vary by country. For full warranty terms and conditions, please refer to the documentation included with your device.
